NOTE: These commands do not apply to the RF linked repeaters.

The PNW220 repeaters are controlled by DTMF commands consisting of one or more digits followed buy a number sign.

The system is divided into several modules each performing a specific task.

You activate a module by sending its module ID followed by a number sign.

Most modules will play their help message if a 0 is sent while the module is active.

* Identify repeater and give date and time.

Sending a single star will make the system identify itself.

Available modules and how to activate them.

0# Activate system Help

Send # to leave help.

1# Activate Parrot

01# Help on Parrot module

The parrot module plays back everything you say. This can be used as a simplex repeater or just to hear how your modjulation sounds.

If you send a DTMF command to the Parrot module,it will read back the received digits.

Exit Parrot mode with a single #

5# Activate METAR information

05# Help on METAR

With Metar information you are able to request worldwide weather information from ICAO weatherstations provided by NOAA.

Currently available stations are:

# 1# 2# 3# 4# 5# 6# 7#

AIRPORTS=KSEA,KOLM,KPAE,KPDX,KAST,KBVS,KBLI

To get a list of predefined stations send 01# while the METAR module is active.

To request METAR info from an available station issue the station number followed by a #.

Example: For Bellingham activate METAR with 5# and send 7# after it's active.

Not issuing a station number will result in a default of KSEA.

Send a single number sign to leave the module.

In addition there are a number of built-in commands not associated with modules

that return information about the repeater.

788# Raspberry pi CPU and UPS status.

401# Outside Temperature

402# Indoor Temperature

403# Transmitter PA Temperature
